肝圆韧带浆膜面在胆道修补中的应用
作者:
通讯作者:
作者单位:

1.江西省肿瘤医院/江西省肿瘤研究所/南昌医学院第二附属医院 肝胆外科,江西 南昌330029;2.江西省德兴市人民医院 外科,江西 德兴 334200;3.江西省赣州市肿瘤医院 外科,江西 赣州 341005;4.江西省抚州市人民医院 肝胆外科,江西 抚州 344000;5.江西省万载县人民医院 外科, 江西 万载336100, China;6.南京医科大学附属泰州人民医院 影像科,江苏 泰州 225300;7.南京医科大学附属泰州人民医院 肝胆外科,江苏 泰州 225300

作者简介:

徐国辉,江西省肿瘤医院/江西省肿瘤研究所/南昌医学院第二附属医院副主任医师,主要从事肝胆外科方面的研究。

基金项目:

江西省优势科技创新团队建设计划基金资助项目(20152BCD24010)。


Application of the serosal surface of the round ligament of the liver in biliary repair
Author:
Affiliation:

1.Department of Hepatobiliary Surgery, Jiangxi Cancer Hospital/Jiangxi Cancer Institute/the Second Affiliated Hospital of Nanchang Medical College, Nanchang 330029, China;2.Department of Surgery, Dexing People's Hospital, Dexing, Jiangxi 334200, China;3.Department of Surgery, Ganzhou Cancer Hospital, Ganzhou, Jiangxi 341005, China;4.Department of Hepatobiliary Surgery, Fuzhou People's Hospital, Fuzhou, Jiangxi 344000, China;5.Department of Surgery, Wanzai People's Hospital, Wanzai, Jiangxi 336100, China;6.Department of Medical Imaging, Taizhou, Jiangsu 225300, China;7.Department of Hepatobiliary Surgery, the Affiliated Taizhou People's Hospital of Nanjing Medical University, Taizhou, Jiangsu 225300, China

Fund Project:

  • 摘要
  • |
  • 图/表
  • |
  • 访问统计
  • |
  • 参考文献
  • |
  • 相似文献
  • |
  • 引证文献
  • |
  • 资源附件
  • |
  • 音频文件
  • |
  • 视频文件
    摘要:

    背景与目的 肝胆外科手术中可因各种原因发生胆管损伤、胆管缺损,如缺损较小可以直接行缝合修补,如缺损较大则往往需要行胆管对端吻合或胆肠Y吻合,后两种手术方式比较复杂,而且胆管对端吻合有可能由于吻合口的张力及血供问题出现胆汁漏、胆管狭窄,而胆肠吻合则改变了正常生理通道,并发症也较多,因此有必要寻求更为安全、有效、简便的胆管修补方法。本研究探讨肝圆韧带浆膜面修补胆管缺损的临床效果及其应用价值。方法 回顾性分析2008年5月—2023年3月6家医院13例采用肝圆韧带浆膜面修补胆管缺损患者的临床资料。结果 13例患者中男性3例,女性10例;年龄40~68岁,平均55.6岁;胆囊结石2例、胃癌1例、胆管炎性狭窄4例、肝左内叶肝细胞癌2例、其他恶性肿瘤4例。术后有6例(46.2%)患者发生胆汁漏,经胆管引流及腹腔引流5例患者于术后7~27 d停止,1例患者于术后56 d停止,无围手术期死亡。7例患者行胆管造影检查,未见胆汁漏、胆管狭窄及胆管结石征象。2例患者行胆管镜检查,未见胆管黏膜与肝圆韧带浆膜之间存在分界。术后随访时间3个月至14年,1例患者出现左侧肝内胆管轻度扩张,考虑肝圆韧带修补的左肝管可能存在狭窄,其余12例患者修补处胆管无狭窄及囊状扩张。结论 肝圆韧带浆膜面修补胆管缺损疗效好,且简单易行,值得临床推广应用。

    Abstract:

    Background and Aims Bile duct injuries and defects can occur during hepatobiliary surgery due to various reasons. Minor defects can be repaired by direct suturing, while more significant defects often require end-to-end bile duct anastomosis or Roux-en-Y cholangiojejunostomy. These latter procedures are more complex and end-to-end anastomosis may lead to bile leakage or bile duct stricture due to tension at the anastomotic site and issues with blood supply. Cholangiojejunostomy alters the normal physiological pathway and is associated with more complications. Therefore, seeking a safer, more effective, and simpler method for bile duct repair is necessary. This study was performed to investigate the clinical efficacy and application value of using the serosal surface of the round ligament of the liver to repair bile duct defects.Methods The clinical data of 13 patients who underwent bile duct defect repair using the serosal surface of the round ligament of the liver in 6 hospitals between May 2008 and March 2023 were retrospectively analyzed.Results Among the 13 patients, 3 were males and 10 were females, with ages ranging from 40 to 68 years (mean age 55.6 years). The underlying conditions included gallstones in 2 cases, gastric cancer in 1 case, inflammatory bile duct stricture in 4 cases, hepatocellular carcinoma in the left inner lobe of the liver in 2 cases, and other malignancies in 4 cases. Postoperative bile leakage occurred in 6 patients (46.2%), with bile leakage resolving in 5 patients within 7 to 27 d after surgery through the bile duct and abdominal drainage and in 1 patient within 56 d after the operation. There were no perioperative deaths. Cholangiography imaging was performed in 7 patients, with no signs of bile leakage, bile duct stricture, or bile duct stones observed. Two patients underwent bile duct endoscopy, showing no demarcation between the bile duct mucosa and the serosa of the round ligament of the liver. The follow-up period ranged from 3 months to 14 years. One patient exhibited mild dilatation of the left intrahepatic bile duct, possibly due to stricture at the left hepatic duct repair site, The other 12 patients showed no stricture or cystic dilatation at the repair site.Conclusion Repairing bile duct defects with the serosal surface of the round ligament of the liver has a good effect and is simple and easy to perform, which is worthy of clinical promotion and application.

    图1 胃癌根治术患者 A:胆总管侧壁缺损(绿箭头);B:经胆总管缺损放置T管,经胆管后方引入7号丝线;C:T管长臂穿过肝圆韧带将肝圆韧带覆盖于胆管缺损的部位;D:结扎7号丝线,将肝圆韧带固定于胆管缺损的部位,同时使T管不易滑脱Fig.1 Patient undergoing radical gastrectomy A: Lateral wall defect of the common bile duct (green arrow); B: A T-tube is placed through the defect of the common bile duct, with a No. 7 suture passed behind the bile duct; C: The long arm of the T-tube passes through the round ligament of the liver, covering the bile duct defect with the round ligament; D: The No. 7 suture is tied to secure the round ligament to the bile duct defect, ensuring the T-tube remains in place
    图2 Mirizzi综合征患者 A:CT提示胆囊壁明显增厚(绿箭头),肝总管显示不清,胆总管内可见结石(白箭头);B:胆管前壁出现严重缺损,放置T管,黄箭头示水肿肥厚的肝圆韧带;C:T管长臂穿过肝圆韧带将肝圆韧带覆盖于胆管缺损的部位;D:术后8年3个月磁共振胆胰管成像(magnetic resonance cholangiopancreatography,MRCP)复查,显示肝内胆管轻度扩张,右肝管未显示,肝总管、胆总管无狭窄及囊状扩张,可见胰胆管合流异常(白箭头);E:T2WI可见右肝管(绿箭头),右肝管无狭窄Fig.2 Patient with Mirizzi syndrome A: CT scan shows significant thickening of the gallbladder wall (green arrow), unclear visualization of the common hepatic duct, and visible stones white arrow in the common bile duct; B: Severe defect in the anterior wall of the bile duct, with a T-tube placed in position; the yellow arrow indicates the edematous and thickened round ligament of the liver; C: The long arm of the T-tube passes through the round ligament of the liver, covering the bile duct defect with the round ligament; D: Magnetic resonance cholangiopancreatography follow-up 8 years and 3 months postoperatively shows mild dilation of the intrahepatic bile ducts, with the right hepatic duct not visible. No stricture or cystic dilation in the common hepatic duct or common bile duct is observed. An anomalous pancreaticobiliary junction is visible (white arrow); E: T2-weighted imaging (T2WI) reveals the right hepatic duct (green arrow) with no stricture
    图3 肝左内叶肝细胞癌患者 A:CT提示肝癌压迫左右肝管及其汇合部;B:左右肝管壁明显菲薄(绿箭头),左肝管上壁出现直径3 mm的圆形缺损(白箭头),胆总管放置T形管;C:肝圆韧带浆膜面覆盖肝门胆管,5-0 Prolene线将肝圆韧带与周围组织缝合固定;D:术后22个月CT复查左侧及右侧肝内胆管无扩张Fig.3 Patient with hepatocellular carcinoma in the left inner lobe of the liver A: CT scan shows liver cancer compressing the left and right hepatic ducts and their confluence; B: The walls of the left and right hepatic ducts are significantly thinned (green arrow), with a 3 mm round defect in the upper wall of the left hepatic duct (white arrow), and a T-tube is placed in the common bile duct; C: The serosal surface of the round ligament of the liver covers the hilar bile ducts, and 5-0 Prolene sutures are used to fix the round ligament to the surrounding tissue; D: CT follow-up 22 months postoperatively shows no dilation of the intrahepatic bile ducts on the left or right side
    图4 胆囊癌患者 A:CT提示胆囊癌侵犯肝门胆管;B:联合切除肝总管及左右肝管前壁,放置Y形管(背面剪有多个侧孔),其长臂自扩张的胆囊管引出;C:肝圆韧带浆膜面覆盖左肝管及肝总管缺损,镰状韧带覆盖右肝管缺损Fig.4 Patient with gallbladder cancer A: CT scan shows gallbladder cancer invading the hilar bile ducts; B: Combined resection of the anterior wall of the common hepatic duct and the left and right hepatic ducts is performed, with a Y-shaped tube (with multiple side holes cut on its posterior side) placed, and its long arm extending out through the dilated cystic duct; C: The serosal surface of the round ligament of the liver covers the defects in the left hepatic duct and common hepatic duct, while the falciform ligament covers the defect in the right hepatic duct
    图5 胆管直管引流,胆总管(绿箭头)内置入拉直的头皮针输液管,管端越过左肝管缺损处,肝圆韧带(黄箭头)覆盖左肝管缺损Fig.5 Straight tube drainage of the bile duct, with a straightened scalp needle infusion tube inserted into the common bile duct (green arrow), the tubes end extending beyond the defect in the left hepatic duct, and the round ligament of the liver (yellow arrow) covering the defect in the left hepatic duct
    参考文献
    相似文献
    引证文献
引用本文

徐国辉,黄国荣,蔡联明,王德进,汪志平,许岩,聂乐乐,邓彬,钟世洪,陈锦华,张长和,陈曦,姜家宝,魏小勇,李小军,饶荣生,周存才.肝圆韧带浆膜面在胆道修补中的应用[J].中国普通外科杂志,2024,33(8):1240-1250.
DOI:10.7659/j. issn.1005-6947.2024.08.005
